Euchner N1ARL502-M 083848 Hassas Tek Limit Anahtarı
0 - Yorum
Kategori
Marka
Stok Kodu
273109
Garanti Süresi
24 Ay
Fiyat
136,79 EUR + KDV
* 1.745,28 TL den başlayan taksitlerle!
6.401,67 TL
Euchner N1ARL502-M 083848
Hassas Tek Limit Anahtarı N1A, uzatılmış makaralı piston
Piston malzemesi paslanmaz çelik
DIN 43693'e göre muhafaza
Approvals
Mechanical values and environment
| Contact bounce time | < 3ms |
| Contact closing time | < 4ms |
| Design | Housing according to DIN 43693 |
| Housing material | |
| Housing | Anodized die-cast alloy |
| Weight | |
| Net | 0,25 kg |
| Ambient temperature | -5 ... 80 °C |
| Degree of protection | IP67 |
| Mechanical life | 30 x 106 |
| Contact material | Silver alloy, gold flashed |
| Switching principle | Snap-action switching contact |
| Installation orientation | Any |
| Number of switching elements | 1 |
| Number of NC contacts | 1 |
| Number of NO contacts | 1 |
| Connection | |
| 2 x | M16 x 1.5 |
| Approach speed | 0,01 ... 20 m/min |
| Actuating element | Extended roller plunger |
| Roller diameter | 18 mm |
| Actuating force | min.20 N |
| Operating point accuracy | ± 0.1 |
Electrical connection ratings
| Thermal rated current Ith | 8 A |
| Utilization category acc. to EN 60947-5-1 | |
| AC-15 | 6A 230V |
| DC-13 | 6A 24V |
| AC-12 | 8 A, 250 V |
| Short circuit protection according to IEC 60269-1 | 8A gG |
| Rated insulation voltage Ui | 250 V |
| Rated impulse withstand voltage Uimp | 2,5 kV |
| Switching current | |
| Min. at DC 12V | 10 mA |
| Connection cross-section | 0,34 ... 1,5 mm² |
